Stainless Steel 304 316 Slotted Countersunk Mushroom Head Bolt

Stainless Steel 304 316 Slotted Countersunk Mushroom Head Bolt

Product Description

Countersunk head screws mostly used in the need to install a raised surface of the part can not place the fastening parts there are two kinds of thickness, the so-called thick, that is fastened to the parts is greater than the thickness of the head of the countersunk head screw thickness after tightening the screw, there is no part of the screw threaded into the threaded hole. This situation, certainly countersunk head screws tightened. Typically there is a situation that is fastened to the part thickness smaller than the height countersunk screw head, which is common in sheet metal parts in machinery and equipment, such as a hinge and the cabinet doors and the coupling of the chassis; sheet metal equipment housing and coupling devices and so on. Due to the small thickness of the part, are fastened sheet metal parts, screws vias completely into a conical bore, in this case, when the countersunk screw is tightened, the screw head is not pressed sheet metal cone , but the top of the screw head and a threaded hole at the bottom of the root Jisi, although the feeling screw is tightened, but the sheet metal is pressed instead of being stuck in this situation, although feeling tighten the screws, but the sheet metal parts really have not been tightened. This is a very common situation.
To tell you the reason for working on: countersunk screw head round vertebrae was 90 ° cone angle, usually bought a new drill apex angle was 118 ° -120 °, the lack of training of some of the workers do not know the angle difference, one often the direct use of reaming drill 120 °, which resulted in not Shen head screws tighten head conical surface difficult, but the bottom line of the screw head is difficult, which is the so-called head screws tight could not reason .

Specification

More details

Application

It is commonly to use them on bare timber, the squared neck giving enough grasp to prevent rotation. General Fastening applications where need high strength and superior corrosion resistance.  Typical applications Construction, Machine repairs, outdoors. Designed for using in high-stress and high-strength applications. The sqaure neck inserted into wood to prevent bolt turning as the nut is tightened.

Advantages

Common chioce for fastening, which provide high tensile, offering high holding power and corrosion resistance and don't need any coating. Competitive prices with professional factory supply. Perfect fastening solution with 10 years experiences to solve your problem: Wide range of parts selection. Durability testing and critical technical design to enhance fasteners lifetime.

More pictures

types of bolts

Bolts

nuts and bolts

Stainless Steel 304 316 Slotted Countersunk Mushroom Head Bolt Images
